Value types

Every property value in a project file is plain JSON. RoFlux looks at what type the property really is, and turns your JSON into that type for you. This page shows how to write each one.

You never write Color3.new or Enum.Material.Neon. You write [255, 0, 0] or "Neon", and RoFlux works out the rest from the property it is going into.

The one rule to remember

Inside a declaration, the shape of a value decides what it is.

• An object { } is a child instance.
• Anything else is a property. That means a number, text, true or false, or an array [ ].

So this does not do what it looks like:

"Floor": {
    "$ClassName": "Part",
    "Size": { "x": 4, "y": 1, "z": 4 }   -- makes a child Folder called Size
}

RoFlux sees an object and builds a child instance named Size. The part keeps its default size. Write it as an array instead, which is always a property:

"Size": [4, 1, 4]

If you really want the object form, put it inside $Properties. Everything in there is a property, whatever its shape:

"$Properties": {
    "Size": { "x": 4, "y": 1, "z": 4 }
}

Quick reference

Numbers, text, and true or false

These go straight through as they are.

"Transparency": 0.5,
"Text": "Play",
"Anchored": true,
"LayoutOrder": 3

Enums

Write just the name of the item. RoFlux already knows which enum the property uses, so you leave off the Enum.Material. part.

"Material": "Neon",
"TextXAlignment": "Left",
"Font": "GothamBold",
"ScaleType": "Fit"

Names are case sensitive. "Neon" works and "neon" does not. Writing the full "Enum.Material.Neon" does not work either.

You can also give the number value, so 288 means the same as "Neon". Names are much easier to read, though.

To find the right name, click the property in Studio's Properties window. The dropdown lists every item it accepts.

Colors

Color3

Three numbers, for red, green and blue.

"Color": [255, 200, 40]      -- 0 to 255, like Color3.fromRGB
"Color": [1, 0.78, 0.16]     -- 0 to 1, like Color3.new
"Color": "#FFC828"           -- hex, when syncing

RoFlux picks the scale for you. If any of the three numbers is above 1, all three are read as 0 to 255. If all three are 1 or below, they are read as 0 to 1.

Hex needs all six digits. The # is optional. Short hex like "#F00" is not read.

BrickColor

The BrickColor name as text, like "Bright red" or "Really black". Its number works too.

Vector3 and Vector2

"Size": [4, 1, 2]              -- Vector3.new(4, 1, 2)
"Position": [0, 10, 0]
"AnchorPoint": [0.5, 0.5]      -- Vector2.new(0.5, 0.5)

Any number you leave off becomes 0, so [4, 1] on a Vector3 gives 4, 1, 0.

Inside $Properties you can also write { "x": 4, "y": 1, "z": 2 }, with lowercase names.

Vector3int16 and Vector2int16 take the same form.

UDim

One axis of a UI size, written as scale then offset. Scale is a fraction of the parent. Offset is pixels.

"CornerRadius": [0.25, 0]      -- UDim.new(0.25, 0)
"PaddingLeft": [0, 12]         -- UDim.new(0, 12)

You see UDim on UICorner, UIPadding, the Padding of a UIListLayout, and similar.

UDim2

This is the one people mix up the most. It is four numbers, in the same order as UDim2.new:

[ xScale, xOffset, yScale, yOffset ]

That is X scale, then X offset, then Y scale, then Y offset. It is not X, Y, X, Y.

A handy way to remember it: fromScale(x, y) puts a 0 after each number, and fromOffset(x, y) puts a 0 before each number.

You can also write it as two UDims, which some people find easier to read:

"Size": [[0.5, 0], [0.25, 0]]

Inside $Properties there is a named form as well, { "ScaleX": 0.5, "OffsetX": 0, "ScaleY": 0.25, "OffsetY": 0 }.

CFrame

Three numbers give just a position:

"CFrame": [0, 10, 0]      -- CFrame.new(0, 10, 0)

To include rotation, give all twelve numbers that CFrame:GetComponents() returns. That is the position, then the nine numbers of the rotation.

"CFrame": [0, 10, 0,  1, 0, 0,  0, 1, 0,  0, 0, 1]

The easy way to get these is to select the part, run print(workspace.Part.CFrame:GetComponents()) in the command bar, and copy what it prints.

Ranges and sequences

NumberRange

"Lifetime": [1, 3]      -- NumberRange.new(1, 3)

When syncing, a single number also works, and sets the min and max to the same value.

NumberSequence

A single number gives a flat value. For a curve, give a list of points. Each point is [time, value], with an optional third number for the envelope.

"Transparency": 0.5
"Transparency": [[0, 0], [0.5, 0.3], [1, 1]]

ColorSequence

A list of [time, color] points. Each color can be hex or three numbers.

"Color": [[0, "#FF0000"], [1, [0, 0, 255]]]

Fonts

Text objects have two font properties, and they take different things.

Font is the older enum, so it takes a name:

"Font": "GothamBold"

FontFace is the newer Font type. Give it the font family, and if you like a weight and a style. Because the value is an object, it has to go inside $Properties:

"$Properties": {
    "FontFace": {
        "family": "rbxasset://fonts/families/GothamSSm.json",
        "weight": "Bold",
        "style": "Italic"
    }
}

Weight is a FontWeight name such as "Regular", "SemiBold" or "Bold". Style is "Normal" or "Italic". Both are optional.

Attributes

Attributes have no fixed type, so RoFlux cannot look one up. It goes by the shape of the value instead.

Anything else, like a color, needs $Type. Otherwise it is skipped.

"$Attributes": {
    "Tint": { "$Type": "Color3", "$Value": [255, 0, 0] }
}

Saying the type yourself

When you want to be exact, wrap the value in $Type and $Value:

"Color": { "$Type": "Color3", "$Value": [255, 0, 0] }

An object holding $Type is always a property, never a child, so this is safe in the shorthand too. It is mostly useful for attributes, since a normal property already knows its own type.

$Type can be any of these: string, number, boolean, Color3, BrickColor, Vector3, Vector2, Vector3int16, Vector2int16, UDim, UDim2, CFrame, Rect, NumberRange, NumberSequence, ColorSequence and Font. Enums are not on the list. For those, just write the name.

Syncing and place files

Syncing converts values inside Studio, using the live property. roflux build converts them on its own, from a list of every Roblox property. Most types work the same both ways. A few are not handled by roflux build yet, and come out empty or at their default in the place file.

If you build place files, the safe choice is the array form for everything. That is the same advice as the rule at the top of this page.

When a value does not work

Open the Changes panel in Studio and pick the Failed filter. Each failure names the instance and says what went wrong.

If a property quietly did nothing and there is no failure at all, check the rule at the top first. An object in the shorthand makes a child instance instead of setting the property.
